| Category |
Item |
Specification |
| OVERALL DIMENSIONS & WEIGHT |
Overall Dimensions (L x W x H) |
5341 x 2032 x 2470 mm |
| Wheelbase |
3300 mm |
| Curb Weight |
2650 kg |
| Gross Vehicle Weight |
3510 kg |
| Approach / Departure Angle |
21 / 25 deg |
| Max Speed |
150 km/h |
| Seating Capacity |
7 persons (including patient) |
| CHASSIS & POWERTRAIN |
Chassis Brand |
Ford Transit / JMC |
| Engine Type |
2.0T Turbo Diesel |
| Engine Power |
121 kW (165 hp) |
| Max Torque |
350 Nm |
| Transmission |
6-speed Manual / Automatic |
| Emission Standard |
Euro VI / National VI |
| Fuel Tank Capacity |
80 L |
| Suspension |
Front: MacPherson Independent; Rear: Leaf Spring |
| Brake System |
Front Ventilated Disc + Rear Disc, ABS + EBD |
| MEDICAL COMPARTMENT |
Compartment Dimensions (L x W x H) |
2620 x 1700 x 1740 mm |
| Compartment Volume |
7.75 m3 |
| Interior Material |
Medical-grade Antibacterial FRP Panel |
| Floor Material |
Anti-slip, Waterproof, Acid-resistant Medical Floor |
| Partition Wall |
FRP Sandwich Panel with Sliding Glass Window |
| Lighting |
LED Ceiling Lights + Surgical Operating Lamp |
| Air Conditioning |
Independent Rear AC + Heating System |
| Ventilation |
Negative Pressure System (Optional), 30 ACH Air Exchange |
| Noise Level |
< 65 dB (at 80 km/h) |
| MEDICAL EQUIPMENT |
Stretcher |
Automatic Loading Stretcher with Safety Belts |
| Stretcher Base |
Aluminum Alloy Guide Rail with Locking System |
| Doctor Seat |
Individual Rotating Medical Seat with Seatbelt |
| Medical Cabinets |
Multi-drawer Medicine Cabinet with Transparent Doors |
| Oxygen System |
2 x 10L Oxygen Cylinders + Pressure Reducer + Flowmeter |
| Suction Device |
Portable Electric Suction Unit |
| Defibrillator Mount |
Universal Bracket for Defibrillator / Monitor |
| IV Hanger |
2 x Retractable IV Drip Stands |
| First Aid Kit |
Standard Trauma First Aid Kit |
| Emergency Light |
LED Warning Light Bar (Red/Blue) + Siren |
| ELECTRICAL SYSTEM |
Power Supply |
12V Vehicle Power + 220V Inverter (2000W) |
| Inverter |
Pure Sine Wave Inverter with Leakage Protection |
| Control Panel |
Centralized Control Panel for All Electrical Devices |
| Battery |
Auxiliary Deep-cycle Battery for Medical Equipment |
| Power Sockets |
Multiple 12V DC + 220V AC Sockets in Compartment |
| External Power |
Shore Power Connection for Stationary Operation |
| SAFETY & OTHER FEATURES |
Safety Features |
Dual Airbags, ABS+EBD, ESP, Tire Pressure Monitor |
| Fire Extinguisher |
2 x Portable Dry Powder Fire Extinguishers |
| Reverse Camera |
HD Rear View Camera + Parking Sensor |
| Communication |
Intercom System between Cabin and Compartment |
| Body Stripe |
High-visibility Emergency Reflective Markings |
| Warranty |
12 Months or 30,000 km Chassis Warranty |
| Customization |
Available in Transport / Monitoring / Negative Pressure Types |
