JMC Ford New Transit V362 (Mid WB Mid Roof) Chassis

Description

Item Parameter
Overall Vehicle Size (mm) L:5341 * W:2080 * H:2680
Medical Cabin Internal Size (mm) Approx.2750 *1580 *1700
Wheelbase (mm) 3300
Gross Vehicle Mass (kg) 3550
Curb Weight (kg) 2830
Suspension System Front MacPherson Independent Suspension / Rear Leaf Spring Non‑independent Suspension
Fuel Type Diesel
Fuel Tank Capacity (L) 70
Engine Model PF2.0T
Working Mode Inline 4‑cylinder Turbocharged Diesel Engine
Displacement (L) 2.0
Power / Horsepower (kw)/(ps) 105 / 142
Max Torque (N·M/rpm) 355 / 1500‑2500
Emission Standard China Ⅵ
Drive Mode Front‑engine Front‑wheel Drive
Transmission 6‑speed Automatic Transmission
Maximum Safe Speed (km/h) 145
Tire Specification 215/75R16C
Brake System Front Disc & Rear Disc
Rated Passengers (including driver) 5‑7 persons
Vehicle Configuration ABS, ESP system;

Roof warning light and siren;

Standard: monitor mounting base, ambulance stretcher, medical cabinet, oxygen supply system, infusion hook;

Optional: negative pressure unit, ventilator, defibrillator, reversing radar & camera, medical‑cabin air conditioner
