Foton Tuyano Long‑WB Mid Roof Chassis Transfer Ambulance

Description

Item Parameter
Overall Vehicle Size (mm) L:5500 * W:2000 * H:2640
Medical Cabin Internal Size (mm) Approx.2820 *1680 *1720
Wheelbase (mm) 3350
Gross Vehicle Mass (kg) 4250
Curb Weight (kg) 2850
Suspension System Front MacPherson Independent Suspension / Rear Leaf Spring Non‑independent Suspension
Fuel Type Diesel
Fuel Tank Capacity (L) 80
Engine Model F2.8NS6B177
Working Mode Inline 4‑cylinder Turbocharged Diesel Engine
Displacement (L) 2.8
Power / Horsepower (kw)/(ps) 130 / 177
Max Torque (N·M/rpm) 360 / 1400‑2800
Emission Standard China Ⅵ
Drive Mode Front‑engine Rear‑wheel Drive
Transmission 6‑speed Manual Transmission
Maximum Safe Speed (km/h) 130
Tire Specification 215/75R16C
Brake System Front Disc & Rear Disc
Rated Passengers (including driver) 5‑7 persons
Vehicle Configuration ABS, ESP system;

Roof warning light and siren;

Standard: patient stretcher, medical cabinet, oxygen supply system;

Optional: negative pressure device, reversing radar & camera, medical‑cabin air conditioner
